Product Overview
McLeod aluminum bellhousings are the gold standard when it comes to accuracy and compact performance. They're constructed of CNC-machined spun aluminum—with a narrow body design for lightness, and a titanium inner liner for added strength and protection. These bellhousing come with a removeable inspection cover to help aide in clutch adjustment between rounds. They come in two different configurations, SFI rated with a steel block plate that gives the bellhousing its SFI 6.1 rating. We also offer a Non- SFI rated version for those customers looking for a light weight bellhousing, but not concerned with a SFI rating so these units do not come with a steel block plate.
Features & Benefits:
- • Constructed of CNC-machined spun aluminum. • Titanium inner liner for added strength and protection. • Removeable inspection cover. • Two different configurations, SFI 6.1 rating and Non- SFI rated versions.
Additional Attributes:
- GTIN: 00887753315830
- Bellhousing Material: Aluminum With Titanium Liner
- Block Plate Included: Yes
- Engine: 1964-1995 SBF
- Flywheel Fitment: Fits 164 Tooth Flywheel Only
- Make: Ford
- NOTE:: This bell housing has a very specific fitment requirement. It requires a SBF with a flywheel that has a 164T Ring Gear and a transmission with a Borg Warner T-5 mounting pattern and input-shaft length. Aftermarket transmissions such as G-Force, Liberty Gears, Rockland Standard Gear, Astro Performance will work as long as the transmission fits the parameters listed above. Call McLeod Tech for further info 714-630-2764.
- SFI Approved: Yes
- Stock Collar I.D.: 4.850In.
- Trans Type: Borg Warner T-5
Extended Information:
- Emissions : CARB Eligible
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 20 x 19 x 7 inches
BellhousingInstructions
